DS18 i48DSP 4-Channel In and 8-Channel Out Bluetooth Audio Receiver

Name: DS18 i48DSP 4-Channel In and 8-Channel Out Bluetooth Audio Receiver
Brand: DS18
Price: 249.95 USD
Availability: OutOfStock

$249.95

Sale Sold out

Free shippingShipping calculated at checkout.

Upgrade your ride with the DS18 i48DSP 4-Channel In and 8-Channel Out Bluetooth Audio Receiver — available at EB Electronics, your local car audio experts.

Power your entire system with confidence. DS18 amplifiers are engineered for clean, stable output — from daily listening to competition builds.

Key Specifications:

4-Channel In and 8-Channel Out
DSP
Bluetooth Audio Receiver
Smartphone Control New 8-IN AND 8-OUT DIGITAL SIGNAL PROCESSORS WITH BLUETOOTH

Every DS18 product we carry is brand new, in original manufacturer packaging, and backed by the manufacturer's warranty. We stock a wide selection in our warehouse so your order ships fast.

What's Included:

(1) Piece of DS18 i48DSP
Original Packaging

Have questions about fitment or installation? Stop by our store or give us a call — our team is happy to help you build the perfect system.

Shipping & Returns

Orders ship fast from our Arizona location. We accept returns within 30 days on eligible items in new condition. Full details.

Warranty

EB Electronics is an authorized DS18 dealer — every product is 100% genuine and carries the manufacturer warranty. See warranty details.

Why Buy From EB

Genuine DS18 gear, fast shipping, and real car audio experts who know this stuff inside out. We also build custom enclosures. About us.

Specifications

Channels	4-Channel In and 8-Channel Out
Operating Voltage	9.5~15V
Power Consumption	300mA
Recommended Fuse Rating	1A
Power Input Terminal Size	16Ga
LED Indicator	Power / BT / Clip / Limiter
Voltmeter	Yes (App)
Remote Turn-on (Input)	Yes
RCA Connector Type	Tiffany
Housing Material	Aluminum
Body Color / Finish	Black / Silver Brushed
Compact Size to Easy Installation for Any Applications	Yes
PCB with Anti-Corrosion Protection Coating	Yes
Surface Mount Component Technology	Yes
Smartphone APP Connectivity	Yes, Android and Apple devices
Settings Presets	Yes, (6 presets / Local Device)
Frequency Response	20Hz-20KHz
S/N Ratio	101dB
THD	0.04%
Input Sensitivity (Low-Level)	200mv-6V
Output Voltage	Up to 3.3V
Balanced Input Noise Rejection	94dB
Stereo Separation	93dB
Time Alignment	0~20ms
DSP Chip	AKM AK7735
Sampling Rate	96KHz/32bit
Signal Conversion AD/DA	CS4344
BT Audio Receiver	5.3v
BT Audio Codec	SBC / ACC
Noise Gate	Yes, adjustable (-60~-120dB)
Routing Channels	Yes, Adjustable with Mixing
Type of Equalizer	Parametric (Each CH) / Graphic (General)
Number of Bands	31 (Each CH / General)
Frequency Point	Selectable (Each CH)
Boost/Cut	18dB(+/-)
Q Factor	0.3~15 (Each CH)
Crossover Ways	8 (Each CH)
Crossover Slopes	ButterWorth 6~48dB/Oct / Bessel 12~48dB/Oct / Linkwitz 12~48dB/Oct
Frequency Cut-off	Selectable 20Hz-20KHz (HPF/LPF/BAND-PASS)
Phase (Polarity)	0?/180? Selectable (Each CH)
Threshold	6~-60dB
Attack	0~200ms
Release	0~990ms
Auto Mode	Yes (Attack and Release)
Overall Length	5.3" / 135mm
Overall Width	3.25" / 83mm
Overall Height	1.3" / 34mm
