DS18

DS18 NXL-IQ Bullet Tweeter

Name: DS18 NXL-IQ Bullet Tweeter
Brand: DS18
Price: 324.95 USD
Availability: OutOfStock

$324.95

Sale Sold out

Size 6.5" 7.7" 8"

Free shippingShipping calculated at checkout.

Upgrade your car's sound system with the crystal-clear tones of our bullet tweeter line. Designed to deliver rich, detailed audio across multiple vehicle configurations, these speakers enhance every note for a truly immersive listening experience.

Specs by size

Size	RMS (W)	Impedance (Ω)	Sensitivity (dB)
6.5"	150	4	90
7.7"	175	4	90
8"	175	4	90

Shipping & Returns

Orders ship fast from our Arizona location. We accept returns within 30 days on eligible items in new condition. Full details.

Warranty

EB Electronics is an authorized DS18 dealer — every product is 100% genuine and carries the manufacturer warranty. See warranty details.

Why Buy From EB

Genuine DS18 gear, fast shipping, and real car audio experts who know this stuff inside out. We also build custom enclosures. About us.

Specifications

Size	6.5" / 7.7" / 8"
RMS Power (6.5")	150 W
RMS Power (7.7")	175 W
RMS Power (8")	175 W
Impedance	4 Ω
Sensitivity	90 dB
SKU	NXL-IQ6/BK
Nominal Diameter	6.5" / 165mm
Nominal Impedance	4 ohms
RMS Power Handling	150W
MAX Power Handling	300W
Sensitivity (1w/1m)	95dB
Frequency Response	45Hz-20KHz
Number of Ways	2-Ways
Recommended High-Pass Crossover	60Hz
Sold in Pair or Single	Pair
UV Protection	Yes, 100% Stable
Marine Grade Type	IP65
LED Lights	Yes, Digital LED integrated (behind cone)
Digital LED Connection Type	12V & Digital IN/OUT terminal
Digital LED Chip Type	1815S
Grill Type	Injection Molded Composite ASA with UV Protection coating
Color / Finish	Matte Black
Specifications	Voice Coil Diameter
1.5" / 38.6mm	Voice Coil Former Material
Glass Fiber	Winding Material
CCAW	Cone Material
PPI	Dust Cap Material
Rubber	Basket Material
Injection Molded Composite PC with UV Protection coating	Magnet Material
Ferrite+Neodymium	Magnet Weight
Floating Bullet Tweeter	Voice Coil Diameter
1" / 25.4mm	Voice Coil Former Material
Kapton	Winding Material
Aluminium	Bullet Material
Neodymium (N35H)	Magnet Weight
Equivalent Volume Vas	3.15L / 0.11ft3
Excursion (one way) Xmax	3mm
Free Air Resonance Fs	94Hz
Mechanical Factor Qms	7.497
Electrical Factor Qes	1.205
Total Factor Qts	1.038
Moving Mass Mms	16.603 g
Compliance Cms	0.1679 mm/N
Bl Factor BI	5.138
Voice Coil Inductance Le	1.4 mH
Diaphragm Area Sd	114.99cm2
DC Resistance Re	3.3 Ohms
Efficiency Bandwidth Product EBP	78.8
Measurement	Overall Diameter
7" / 177mm	Overall Depth
3.75" / 95mm	Front Mount Baffle Cutout
5.3" / 135mm	Mounting Depth
2.5" / 63mm	Motor Diameter
