XS Power PWR-S5 12V Titan8 Lithium Titanate (LTO) Battery

The XS Power PWR-S5 12V Titan8 Lithium Titanate (LTO) Battery establishes the performance baseline for the entire PWR-S5 platform. This non-group-specific 12V lithium titanate unit is ideal for fabricators and competition teams, offering dimensional flexibility for custom builds.

Utilizing advanced LTO chemistry, the PWR-S5 delivers an impressive max amps rating and ten amp-hours of capacity. This provides both the high-burst output required for competition SPL duty and sufficient reserve to sustain high-output systems through extended sessions. Designed for unbeatable cranking power, this Lithium Titanate Oxide (LTO) Series uses a high-power lithium cell engineered for high-burst output (up to 100 times its capacity) and very high-charge current (30 to 60 times its capacity).

A single 10Ah module can support burst current up to 1,000 amps and accept 300 amps of continuous charge current. The built-in 2/0 bussing allows up to four positive and four negative hidden direct connections, while still providing two easily accessible top terminals and four series or parallel expansion terminals for building banks of various configurations (12V, 24V, 36V, etc.). Weighing only eight pounds, it contributes minimal weight to the overall build, and its fast charge acceptance pairs well with high-output alternators to keep voltage consistently elevated. This modular Titan8 model is not suitable for under-hood use; XS Power offers BCI direct-fit models for such applications.
